Description
Introduction to Infusion Sets
Infusion sets play a pivotal role in modern medical care, facilitating the controlled delivery of fluids, medications, and nutrients to patients. Although infusion and transfusion share the common goal of introducing substances into the body, they pertain to different aspects within similar medical processes.
Gravity infusion, a widely – used method, is particularly suitable for administering intermittent medications. This approach is favored for medications that have a restricted shelf – life post – admixture. On the other hand, the transfusion of blood and its components has become an essential part of daily clinical practice. Medical personnel are acutely focused on handling patients’ blood, a precious and scarce resource, with the utmost responsibility.
As a leading manufacturer of infusion set types, we understand the diverse needs of our clients. Depending on different usage scenarios and patient requirements, we offer a variety of material options. This ensures that our infusion tubing sets can meet specific user needs precisely. Moreover, we provide our customers with the freedom to flexibly choose the configuration of accessories. This customization makes our infusion tubing sets more targeted and professional. Currently, our inventory boasts an extensive range of infusion sets, including safety infusion sets, butterfly infusion sets, micro – infusion sets, pediatric infusion sets, winged infusion sets, Y – type infusion sets, and more.
Benefiting from years of industry experience, we have established partnerships with numerous excellent raw material and accessory suppliers. This enables us to offer infusion sets at more favorable prices while providing highly professional services. If you are in the market to purchase infusion sets, do not hesitate to contact us.
Types of Infusion Sets
Vented Spike Infusion Sets
- Application: Ideal for use with both infusion bags and bottles.
- Drip Rate: The set is calibrated such that 20 drops equal 1 ± 0.1ml, ensuring accurate fluid administration.
- Drip Chamber: Features a flexible drip chamber, which allows for easy visualization of the fluid flow and helps in controlling the rate.
- Clamping Mechanism: Equipped with a roller clamp for convenient adjustment of the flow rate.
- Adapter: Comes with either a slip or lock adapter, providing versatility in connecting to other medical devices.
- Injection Site: Offers a latex or latex – free injection site, catering to patients with different sensitivities.
- Usage: Designed for gravity – based infusion and is sterile, guaranteeing a safe and contamination – free administration process.
Non – Vented Spike Infusion Sets
- Application: Specifically designed for infusion bags.
- Drip Rate: Available with multiple drip rate options: 10/15/20/60 drops = 1 ± 0.1 ml, enabling customization based on the type of fluid and patient’s requirements.
- Components: Has a flexible drip chamber, along with roller clamp, slip clamp, and a filter. The filter helps in removing any particulate matter from the fluid.
- Injection Port: Features a Y – injection port, allowing for the addition of additional medications or fluids.
- Adapter: Similar to the vented spike sets, it comes with a slip or lock adapter.
- Usage: Intended for gravity – driven infusion and is sterile.
Flow – Controlled Infusion Sets
- Application: Suitable for both infusion bags and bottles.
- Drip Rate: Offers the same range of drip rates as the non – vented spike sets: 10/15/20/60 drops = 1 ± 0.1ml.
- Unique Feature: Incorporates a precise flow – control mechanism, ensuring accurate and consistent fluid delivery.
- Adapter and Injection Site: Equipped with a slip or lock adapter and an injection site for additional medication administration.
- Usage: Designed for gravity – based infusion and is sterile.
Opaque Infusion Sets
- Application: Compatible with infusion bags and bottles.
- Drip Rate: Has a drip rate of 10/15/20/60 drops = 1 ± 0.1ml.
- Components: Features a flexible drip chamber, roller camp, and slip clamp for flow control. It also includes an injection site.
- Adapter and Needle: Comes with a slip or lock adapter and a needle, which may be useful in certain clinical scenarios.
- Usage: Intended for gravity – based infusion and is sterile.
Precise Filter Infusion Sets
- Application: For use with infusion bags and bottles.
- Drip Rate: Offers a drip rate of 10/15/20/60 drops = 1 ± 0.1ml.
- Components: Similar to other sets, it has a flexible drip chamber, roller clamp, and slip clamp. The injection site allows for medication addition.
- Adapter and Needle: Equipped with a slip or lock adapter and a needle.
- Usage: Designed for gravity – based infusion. While the set is highly effective in filtering particles, it’s important to note that the product description does not explicitly state if it’s sterile in this section, but based on the overall context, it can be assumed to be sterile like other sets.
Infusion Sets with Burette
- Burette Features: These sets come with a 100 or 150ml graduated burette equipped with a shut – off valve. The burette allows for precise measurement of the fluid being infused.
- Drip Rate: With a drip rate of 60 drops = 1 ± 0.1ml.
- Drip Chamber: The flexible drip chamber comes with a filter to ensure the purity of the infused fluid.
- Clamping and Adapter: Features a roller clamp and a slip or lock adapter with a protective cap. It also has a latex or latex – free injection site.
- Usage: Designed for gravity – based infusion and is sterile.
Infusion Pump Administration Sets
- Application: Specifically designed for use with infusion pumps and are compatible with infusion bags and bottles.
- Components: Features a flexible drip chamber and a Y – injection port for adding medications.
- Adapter: Equipped with a lock adapter for a secure connection to the infusion pump.
- Usage: Intended for use with infusion pumps and is sterile.
TPE Material Infusion Sets
- Material Advantage: Made from TPE (Thermoplastic Elastomer), these sets are non – PHT and non – PVC. They also feature an automatic air – bubble extinguishing device, which helps in preventing air embolisms.
- Components: Similar to other sets, it has a flexible drip chamber, roller clamp, sip clamp, Y – injection port, and a slip or lock adapter.
- Usage: Designed for gravity – based infusion and is sterile.
Details of Infusion Sets
Main Materials
Our infusion sets are crafted from a variety of high – quality materials, including PP (Polypropylene), PVC (Polyvinyl Chloride), TPE (Thermoplastic Elastomer), PVC (without PHT – Phthalates), ABS (Acrylonitrile Butadiene Styrene), SUS304 stainless steel cannula, Isoprene rubber, and silicone oil. Each material is carefully selected for its specific properties, such as flexibility, durability, and biocompatibility.
Product Conformance
Our infusion sets conform to ISO 8536 – 4 standards. They are also in compliance with the European Medical Device Directive 93/42/EEC. For sets with a needle, they fall under CE Class IIa, and for sets without a needle, they are classified as CE Class I.
Quality Assurance
The manufacturing process of our infusion sets adheres to the ISO 13485 and ISO 9001 Quality Systems. This ensures that every product leaving our facility meets the highest quality and safety standards, providing our customers with reliable and trustworthy infusion solutions.
